| FRAME | Nukeproof Megawatt 297 Alloy, 170mm Travel, custom triple butted hydro-formed tube set, internal Battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured Rubber frame protection, Shimano STEPS compatible. | Nukeproof Megawatt 297 Alloy, 170mm Travel, custom triple butted hydro-formed tube set, internal Battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured Rubber frame protection, Shimano STEPS compatible. | Nukeproof Megawatt 297 Alloy, 170mm Travel, custom triple butted hydro-formed tube set, internal Battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured Rubber frame protection, Shimano STEPS compatible. | Nukeproof Megawatt 297 Alloy, 170mm Travel, custom triple butted hydro-formed tube set, internal Battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured Rubber frame protection, Shimano STEPS compatible. |
|---|
| FORK | RockShox Domain, 29”, Motion Control RC damper, 170mm, 44mm Offset, BOOST, Debonair, 1.8 Tapered Steerer, Gloss Black | Fox 38 Float, 29”, Performance Elite Series, Grip 2 Damper, 170mm, 44mm Offset, BOOST, 1.5T Steerer, 68mm Crown, Black | Fox 38 Float, 29”, Factory Series, Kashima, Grip 2 Damper, 170mm, 44mm Offset, BOOST, 1.5T Steerer, 68mm Crown, Black | RockShox Zeb Ultimate Charger 2.1 RC2 170mm, 44mm Offset, BOOST, Debonair, Grey |
|---|
| SHOCK | RockShox Super Deluxe Select R, Custom LIN L1 HOTDOG tune, 230x62.5mm, Bearing End, 2 bottomless tokens fitted. | Fox Float X2, Performance Series, EVOL, 2 Position lever, Custom LCL LRL tune, 230x62.5mm, Bearing End, 2x 0.3 spacer fitted. | Fox Float X2, Factory Series, Kashima, EVOL, 2 Position lever, Custom LCL LRL tune, 230x62.5mm, Bearing End, 2x 0.3 spacer fitted. | RockShox Super Deluxe Ultimate RCT Coil, Custom LNL / L1 Hotdog (S/MD) LNL / L Hotdog (L/XL/XXL) S320 tune, 205x65mm, Bearing End, Spring S:400lbs; MD/L:450lbs; XL:500lbs; XXL:550lbs |
|---|
| WHEELSET | Front Wheel: Sun-Ringle Duroc SD37 Comp 29"", 15x110mm // Rear Wheel: Sun-Ringle Duroc SD37 Comp 27.5"", Shimano Microspline Driver, 148x12mm | Front Wheel:Nukeproof Horizon V2, 29"", 6 Bolt, 110x15mm // Rear Wheel Nukeproof Horizon V2, 27.5"", 6 Bolt, Shimano Microspline Driver, 148x12mm | Front wheel: DT Swiss H1700 SPLINE 30, 29"", 6 Bolt, 110x15mm // Rear wheel: DT Swiss H1700 SPLINE 30, 27.5"", 6 Bolt, Shimano Microspline Driver, 148x12mm | Front Wheel:Nukeproof Horizon V2, 29"", 6 Bolt, 110x15mm // Rear Wheel Nukeproof Horizon V2, 27.5"", 6 Bolt, XD Driver, 148x12mm |
|---|
| DRIVE SYSTEM | Shimano STEPS EP8, 250W, 85Nm | Shimano STEPS EP8, 250W, 85Nm | Shimano STEPS EP8, 250W, 85Nm | Shimano STEPS EP8, 250W, 85Nm |
|---|
| CRANKS | Shimano EM600, 165mm, 34t, 52mm chainline | Shimano EM600, 165mm, 34t, 52mm chainline | Shimano EM8150 XT, HOLLOWTECH II, 165mm, 34T, 52mm Chainline | Shimano EM8150 XT, HOLLOWTECH II, 165mm, 34T SRAM Eagle Chain ring, 52mm Chainline |
|---|
| DISPLAY | Shimano EM800 with Shimano EM800-L Assist Switch | Shimano EM800 with Shimano EM800-L Assist Switch | Shimano EM800 with Shimano EM800-L Assist Switch | Shimano EM800 with Shimano EM800-L Assist Switch |
|---|
| BATTERY | Shimano E8035, 504Wh | Shimano E8036, 630Wh | Shimano E8036, 630Wh | Shimano E8036, 630Wh |
|---|
| SHIFTER | Shimano Deore M6100-IR, 12-speed Rapidfire Plus, I-Spec EV | Shimano SLX M7100-IR, 12-speed Rapidfire Plus, I-Spec EV | Shimano XT M8100-R, 12-speed Rapidfire Plus, I-Spec EV | SRAM Eagle AXS 12-Speed, Black |
|---|
| REAR DERAILEUR | Shimano Deore M6100, SGS 12-Speed, Shadow Plus | Shimano SLX M7100, SGS 12-Speed, Shadow Plus | Shimano XT M8100, SGS 12-Speed, Shadow Plus | SRAM XO1 AXS Eagle 12-Speed, Black |
|---|
| CHAIN | Shimano Deore M6100 12-Speed | Shimano SLX M7100 HG 12-speed Inc Quicklink | Shimano XT M8100 HG 12-speed Inc Quicklink | SRAM GX Eagle 12-Speed |
|---|
| CASSETTE | Shimano Deore M6100 12-Speed (HYPERGLIDE+), 10-51T | Shimano SLX M7100-12, 12-Speed (HYPERGLIDE+), 10-51T | Shimano XT M8100-12, 12-Speed (HYPERGLIDE+), 10-51T | SRAM XO1 Eagle 12-Speed, CS XG1295 EAGLE 10-52T |
|---|
| CHAIN GUIDE | Shimano EM800 drive unit mount | Shimano EM800 drive unit mount | Shimano EM800 drive unit mount | Shimano EM800 drive unit mount |
|---|
| BRAKES | SRAM DB8 | Shimano SLX M7120, 4 Pot Brake, Metallic Pads | Shimano XT M8120, 4 Pot Brake, Metallic Pads | SRAM Code RSC, Sintered pads |
|---|
| ROTORS | SRAM 220mm Front / 200mm Rear | Brakco 220mm Front / 200mm Rear | Shimano SM-RT76, 220mm Front / 203mm Rear | SRAM Centerline 220mm Front / 200mm Rear |
|---|
| TYRES | Front: Maxxis Assegai 29”x2.5 WT 3C MaxxGrip/DD/TR, Rear: Maxxis Assegai 27.5”x2.5 WT 3C MaxxGrip/DD/TR | Front: Maxxis Assegai 29”x2.5 WT 3C MaxxGrip/DD/TR, Rear: Maxxis Assegai 27.5”x2.5 WT 3C MaxxGrip/DD/TR | Front: Maxxis Assegai 29”x2.5 WT 3C MaxxGrip/DD/TR, Rear: Maxxis Assegai 27.5”x2.5 WT 3C MaxxGrip/DD/TR | Front: Micheline DH22 TLR 29”x2.4, Rear: Micheline DH22 TLR 27.5”x2.4 |
|---|
| HANDLEBARS | Nukeproof Neutron V2, S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm | Nukeproof Horizon V2, Width - S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm | Nukeproof Horizon V2, Width - S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm | Nukeproof Nukeproof Horizon Carbon V2, S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm |
|---|
| STEM | Nukeproof Neutron AM, 45mm, black | Nukeproof Horizon, 45mm, Black | Nukeproof Horizon, 45mm, Black | Nukeproof Horizon, 45mm, Black |
|---|
| SADDLE | Nukeproof, Black | Nukeproof, Black | Nukeproof, Black | Nukeproof, Black |
|---|
| SEATPOST | Brand X Ascend internal, 31.6mm, S:125mm drop; M:150mm drop; L: 170mm drop; XL/XXL: 200mm drop | Brand X Ascend internal with Brand-X Remote lever, S:125mm drop; M:150mm drop; L:170mm drop; XL/XXL:200mm drop | Bikeyoke Divine Stealth with Brand-X Remote lever, S:125mm drop; M:160mm drop; XL/XXL:185mm drop | Bikeyoke Revive with Triggy 1x Remote, 31.6mm; S:125mm drop; M:160mm drop; L:185mm drop; XL/XXL:213mm drop |
|---|
| HEADSET | Acros AZX-589, sealed bearings, ZS56/28.6 – ZS66/38 | Acros AZX-589, sealed bearings, ZS56/28.6 – ZS66/39 | Acros AZX-589, sealed bearings, ZS56/28.6 – ZS66/40 | Acros AZX-589, sealed bearings, ZS56/28.6 – ZS66/41 |
|---|
| GRIPS | Nukeproof Sam Hill Signature | Nukeproof Sam Hill Signature | Nukeproof Sam Hill Signature | Nukeproof Sam Hill Signature |
|---|
| BATTERY CHARGER | Shimano E6002 | Shimano E6002 | Shimano E6002 | Shimano E6002 |
|---|
| WEIGHT: (SIZE MEDIUM) | 24.1Kgs Medium (Tubeless) | 24.6Kgs Medium (Tubeless) | 24.25Kgs Medium (Tubeless) | 24.69Kgs Medium (Tubeless) |
|---|
