Uncomplicated and incredibly versatile, Quick Haul Long is a compact cargo bike for families on the go. It’s similar in length to a regular bike for easy maneuvering past traffic queues, but built extra tough to safely carry 2 kids or your biggest Costco hauls. And best of all, it’s a funner, freer way to get around for you and your family without putting strain on the environment.
Uncomplicated and incredibly versatile, Quick Haul Long is a compact cargo bike for families on the go. It’s similar in length to a regular bike for easy maneuvering past traffic queues, but built extra tough to safely carry 2 kids or your biggest Costco hauls. And best of all, it’s a funner, freer way to get around for you and your family without putting strain on the environment.
Tern

Tern Quick Haul Long D9 500wh Satin in Black

£3,600.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Hassle free returns

You have the right under The CCR (Consumer Contracts Regulations) 2014 which states that up to 14 days after receiving your goods, in most cases, you can change your mind and get a full refund. You have the right to cancel this contract within 14 days from delivery without giving any reason. This right does not apply to any customised or personalised goods bought through our website. To exercise this right please Contact Us prior to the expiry of the cancellation rights period.

If you cancel this contract, we will reimburse to you all payments received from you, including the costs of delivery (except for the supplementary costs arising if you chose a type of delivery other than the least expensive type of standard delivery offered by us).

We may make a deduction from the reimbursement for loss in value of any goods supplied, if the loss is the result of unnecessary handling by you.

We will make the reimbursement without undue delay, and not later than 14 days after the day we received back from you any goods supplied; or (if earlier) 14 days after the day you provide evidence that you have returned the goods; or if there were no goods supplied, 14 days after the day on which we are informed about your decision to cancel this contract.

We will make the reimbursement using the same means of payment as you used for the initial transaction, unless you have expressly agreed otherwise; in any event, you will not incur any fees as a result of the reimbursement.

The CRA (Consumer Rights Act) 2015 states that goods must be as described, fit for purpose and of satisfactory quality. During the expected lifespan of your product you're entitled to the following; up to 30 days, if your goods are faulty, then you can get a refund. Up to six months, if they can't be repaired or replaced, then you're entitled to a full refund, in most cases, up to six years, if the goods do not last a reasonable length of time, you may be entitled to some money back.

Nothing in this contract affects your legal rights under the Consumer Rights Act 2015 (also known as ‘statutory rights’). You may also have other rights in law.

Thanks for your support,

The Friction Cycles Team.

Tern Quick Haul Long D9 500wh Satin in Black

Brand:Tern

Code:810067165846

Riding while carrying all that weight may sound intimidating, but you’re in good hands with the Quick Haul Long. Its long wheelbase combined with a low center of gravity ensures your ride remains stable even with an ambitious haul, while a low step-through frame makes getting on and off effortless. And at under 30 kg (66 lb) including the battery, even smaller riders will find themselves capable of handling the Quick Haul Long.
Technical Information

SPECIFICATIONS

General Info
Generation:
Gen 1
Color(s):
Speeds:
1 x 9
Weight:
29.3 kg (64.6 lb)
Gear Inches:
23" - 89" (1.87 - 7.13 m)
Frame Sizes:
One size
Bike Size:
187 × 70 × 102.5 cm (73.6 × 27.6 × 40.4 in)
Wheelbase:
130 cm (51.2 in)
Standover Height:
48 cm (18.9 in)
Distance: Seatpost to Handlebar:
60 - 64 cm (23.6 - 25.2 in)
Distance: Saddle to Pedal:
76 - 99 cm (29.9 - 39 in)
Suggested Rider Height:
155 - 190 cm (61 - 74.8 in)
Max Gross Vehicle Weight:
190 kg (418.9 lb)
Max Rider Weight:
120 kg (264.6 lb)
Frame
Frame:
Tern Quick Haul Long, Patented Design, 6061-AL, DIN 79010 certified: 190 kg (419 lb)
Fork:
Cargo, Aluminum alloy, DIN 79010 certified: 190 kg (419 lb)
Cockpit
Stem:
Speedlifter, adjustable, 3D forged stem, 31.8
Headset:
TH, cartridge bearings
Handlebar:
Low riser ergo, 31.8, 6061-AL
Grips/Bar Tape:
Velo ergonomic, lock-on
Saddle:
Velo Comfort
Seatpost:
34.9 mm, 6061-AL, micro-adjust clamp
Seatpost Clamp:
Tern Collar
Brakes
Front Brake:
Tektro hydraulic disc
Rear Brake:
Tektro hydraulic disc
Brake Levers:
Tektro hydraulic disc
Wheels
Front Hub:
Disc, aluminum
Rear Hub:
9 spd, disc, aluminum, Boost
Spokes & Nipples:
Stainless steel
Rims:
Tern Atlas H, cargo
Tyres:
Tern x Schwalbe Super Moto-X, Green Guard puncture protection, Reflex
Transmission
Shifter:
Tektro, 1 x 9 spd, trigger
Rear Derailleur:
Tektro custom for Tern, 1 x 9 spd
Crankset:
Tern custom, forged 6061-AL crankarm, anti-drop chainring
Cassette/Freewheel:
Tektro 11-42T, 9 spd
Bottom Bracket:
Motor integrated
Chain:
KMC for eBike, 9 spd
Pedals:
Urban with non-slip surface
Shifter Cable & Housing:
SP
E-System
Motor:
Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
Battery:
Bosch PowerPack 400
Display:
Bosch Purion, 4 mode selectable, walk assist
Range:
400 Wh: 42-85 km (26-53 mi)
Charger:
220V, 4A (EU); 100-240V, 4A (US)
Bells & Whistles
Bell:
Aluminum
Chainguard:
SKS Chainblade
Kickstand:
Atlas Kickstand, for cargo
Luggage Socket:
Combo Mount
Front Light:
90 lux, StVZO approved
Rear Light:
Herrmans
Fenders:
SplashGuard, stainless hardware
Rack:
Atlas L, 90 kg (198 lb) capacity
Frame Lock:
ABUS or AXA, keyed-alike with Bosch battery

*Note: These are our standard model specifications. The bike's weight and folded dimension may not include racks and fenders. The specifications for your country may differ slightly. We do our best to ensure that the specifications listed here accurately reflect the exact parts found on our production bikes. However, component changes do occur for various reasons and there may be brief delays on site updates. We reserve the right to make component changes without prior notification, which may cause discrepancies with the information listed on the web.

Sizing Information
Sharing a car with your spouse or partner makes sense, and it shouldn’t be any different for an e-bike. Quick Haul Long is made for easy sharing—with the flip of two levers, the stem and seatpost adjust in seconds without tools to fit riders 155 - 190 cm (5'1" - 6'3") tall, while a low step-through frame facilitates easy mounting and dismounting.
